Small dimension match the minimum cabinet application.
User-centered design with good operation experience.
Easy to upgrade to high efficiency version of 94%.
Wide AC input range (90Vac～290Vac).
Wide operating temperature (-40℃～+70℃).
2*800W maximum power, redundant 1 + 1.
Optional Battery module.
Batteries Temperature compensation.
Flexible management with in-band and out-band.
In-band integrated management into N2000 with RS485.
Out-band TCP/IP, SNMP V3, Onboard secure web server, intelligent remote management function with RS485/RS232/10/100BaseT Ethernet.
Modular design with hot-plug.
LCD display with user-friendly menus and simplified keypad.
Optional management software remotely upgrades.
LCD display with user-friendly menus and simplified keypad.
Optional management software remotely upgrades.
|
Specification |
|
| Input rating | 110/120 V AC to 200/240 V AC |
| Input voltage frequency | 50 Hz to 60 Hz |
| Maximum output power (W) | 3840 W (176–290 VA C); 1920 W (90–175 VA C) |
| Total output | 53.5 V; 37.5 A/53.5 V; 75A |
