Huawei HN8546X6 ONT

  • Failure rate<0.2%
  • OEM Supported
  • Firmware Customized
  • Supports TR069/OMCI
Available:In Stock
$0.00

The Huawei OptiXstar HN8546X6 is an XG-PON and Wi-Fi 6 routing-type ONT. It uses the XG-PON and Wi-Fi 6 technologys to implement ultra-broadband access, high performance and wide coverage for users. The user-side rate of a Huawei 10G PON ONT can reach up to 1000 Mbit/s, meeting requirements of home users on bandwidth-hungry services such as 4K/8K HD video, AR/VR, home cloud, and video calls. It can also provide private line access services of up to 10 Gbit/s.

It provides 4 GE ports, 1 POTS port, 2 USB port and 1 2.4G&5G Wi-Fi 6 port.
2.5 Gbit/s upstream, 10 Gbit/s downstream
Receiver sensitivity: -28 dBm
Wavelengths: US 1260-1280 nm, DS 1575-1580 nm
IEEE 802.11 b/g/n/ax (2.4G)
IEEE 802.11 a/n/ac/ax (5G)
2×2 MIMO (2.4G)
2×2 MIMO (5G)
Antenna gain: 5 dBi
OMCI/Web UI/TR069
Variable-length OMCI messages

Specification
UNI Huawei HN8546X6 ONT
Working environment Operating temperature: 0ºC to 40ºC
Environment humidity: 5% to 95% (noncondensing)
Max. power consumption 18 W
Power specifications Power adapter input: 170 ~ 240 V AC,50/60 Hz
System power supply: 11 ~14V DC, 1.5 A
WLAN

IEEE 802.11 b/g/n/ax(2.4G)

IEEE 802.11 a/n/ac/ax(5G)

2×2 MIMO(2.4G&5G)

Antenna gain: 5 dBi

WMM/Multiple SSIDs/WPS

Air interface rate: 574 Mbit/s (2.4G), 2402 Mbit/s (5G)

Network-side Port XG-PON
User-side Ports 1 x POTS + 4 x GE + 2 x USB + 2.4G/5G 11ax Wi-Fi 6
Indicators POWER/REG/PON/LAN 1-4/TEL/USB/WLAN/WPS
Dimensions
(length x width x height)

40mm x 185mm x 120mm

Weight About 400 g

Differences Between 10G GPON and GPON

Specifications GPON 10G GPON
XG-PON XGS-PON
Wavelength Downstream: 1480-1500 nm Downstream: 1575-1580 nm Downstream: 1575-1580 nm
Upstream: 1290-1330 nm Upstream: 1260-1280 nm Upstream: 1260-1280 nm
Center wavelength Downstream: 1490 nm Downstream: 1577 nm Downstream: 1577 nm
Upstream: 1310 nm Upstream: 1270 nm Upstream: 1270 nm
Maximum Line Rate Downstream: 2.488 Gbit/s Downstream: 9.953 Gbit/s Downstream: 9.953 Gbit/s
Upstream: 1.244 Gbit/s Upstream: 2.488 Gbit/s Upstream: 9.953 Gbit/s
Maximum Physical Transmission Distance 60 km 100 km 100 km
NOTE: NOTE: NOTE:
The physical reach is defined by split ratio, optical module size, and fiber quality. The physical reach is defined by split ratio, optical module size, and fiber quality. The physical reach is defined by split ratio, optical module size, and fiber quality.
Maximum Split Ratio 1:128 1:256 1:256
NOTE: NOTE: NOTE:
The actual split ratio depends on the optical module model and fiber distance. The actual split ratio depends on the optical module model and fiber distance. The actual split ratio depends on the optical module model and fiber distance.

HN8546X6 Similar Huawei 10G GPON ONTs

ONT Model UNI
HN8346V5 XG-PON ONT, 4GE+1POT+2USB+2.4G/5G WIFI
HN8145V(black) XG-PON ONT, 4*GE+1*POTS+1*USB+2.4G/5G WIFI
HN8245Q XG-PON ONT, 4GE+1POTS+2USB+2.4G/5G WIFI
HN8546X6 XG-PON ONT, 4GE+2USB+1POT, 2.4G/5G WIFI 6
EN8145X6 XG-PON ONT,4GE+1USB+1POT, 2.4G/5G WIFI 6



The Huawei OptiXstar HN8546X6 is an XG-PON and Wi-Fi 6 routing-type ONT. It uses the XG-PON and Wi-Fi 6 technologys to implement ultra-broadband access, high performance and wide coverage for users. The user-side rate of a Huawei 10G PON ONT can reach up to 1000 Mbit/s, meeting requirements of home users on bandwidth-hungry services such as 4K/8K HD video, AR/VR, home cloud, and video calls. It can also provide private line access services of up to 10 Gbit/s.

It provides 4 GE ports, 1 POTS port, 2 USB port and 1 2.4G&5G Wi-Fi 6 port.
2.5 Gbit/s upstream, 10 Gbit/s downstream
Receiver sensitivity: -28 dBm
Wavelengths: US 1260-1280 nm, DS 1575-1580 nm
IEEE 802.11 b/g/n/ax (2.4G)
IEEE 802.11 a/n/ac/ax (5G)
2×2 MIMO (2.4G)
2×2 MIMO (5G)
Antenna gain: 5 dBi
OMCI/Web UI/TR069
Variable-length OMCI messages

Specification
UNI Huawei HN8546X6 ONT
Working environment Operating temperature: 0ºC to 40ºC
Environment humidity: 5% to 95% (noncondensing)
Max. power consumption 18 W
Power specifications Power adapter input: 170 ~ 240 V AC,50/60 Hz
System power supply: 11 ~14V DC, 1.5 A
WLAN

IEEE 802.11 b/g/n/ax(2.4G)

IEEE 802.11 a/n/ac/ax(5G)

2×2 MIMO(2.4G&5G)

Antenna gain: 5 dBi

WMM/Multiple SSIDs/WPS

Air interface rate: 574 Mbit/s (2.4G), 2402 Mbit/s (5G)

Network-side Port XG-PON
User-side Ports 1 x POTS + 4 x GE + 2 x USB + 2.4G/5G 11ax Wi-Fi 6
Indicators POWER/REG/PON/LAN 1-4/TEL/USB/WLAN/WPS
Dimensions
(length x width x height)

40mm x 185mm x 120mm

Weight About 400 g

Differences Between 10G GPON and GPON

Specifications GPON 10G GPON
XG-PON XGS-PON
Wavelength Downstream: 1480-1500 nm Downstream: 1575-1580 nm Downstream: 1575-1580 nm
Upstream: 1290-1330 nm Upstream: 1260-1280 nm Upstream: 1260-1280 nm
Center wavelength Downstream: 1490 nm Downstream: 1577 nm Downstream: 1577 nm
Upstream: 1310 nm Upstream: 1270 nm Upstream: 1270 nm
Maximum Line Rate Downstream: 2.488 Gbit/s Downstream: 9.953 Gbit/s Downstream: 9.953 Gbit/s
Upstream: 1.244 Gbit/s Upstream: 2.488 Gbit/s Upstream: 9.953 Gbit/s
Maximum Physical Transmission Distance 60 km 100 km 100 km
NOTE: NOTE: NOTE:
The physical reach is defined by split ratio, optical module size, and fiber quality. The physical reach is defined by split ratio, optical module size, and fiber quality. The physical reach is defined by split ratio, optical module size, and fiber quality.
Maximum Split Ratio 1:128 1:256 1:256
NOTE: NOTE: NOTE:
The actual split ratio depends on the optical module model and fiber distance. The actual split ratio depends on the optical module model and fiber distance. The actual split ratio depends on the optical module model and fiber distance.

HN8546X6 Similar Huawei 10G GPON ONTs

ONT Model UNI
HN8346V5 XG-PON ONT, 4GE+1POT+2USB+2.4G/5G WIFI
HN8145V(black) XG-PON ONT, 4*GE+1*POTS+1*USB+2.4G/5G WIFI
HN8245Q XG-PON ONT, 4GE+1POTS+2USB+2.4G/5G WIFI
HN8546X6 XG-PON ONT, 4GE+2USB+1POT, 2.4G/5G WIFI 6
EN8145X6 XG-PON ONT,4GE+1USB+1POT, 2.4G/5G WIFI 6
