Huawei CR5D00E4XM25 Flexible Sub-Card
Review: 5 - "A masterpiece of literature" by , written on May 4, 2006
I really enjoyed this book. It captures the essential challenge people face as they try make sense of their lives and grow to adulthood.

Huawei CR5D00E4XM25 Flexible Sub-Card

  • Board Functional Testing
  • Hardware Compatibility Testing
Available:In Stock
$0.00

Huawei NE8000 M4, M8 and M14 4-Port 25GE(SFP28)/10GE(SFP+) MACsec Physical Interface Card (PIC) CR5D00E4XM25 PN# 03033BLK

CR5D00E4XM25 is 8-Port 100/1000Base-RJ45 Physical Interface Card(PIC) used for Huawei NE8000 Series Router NetEngine 8000 M14, NetEngine 8000 M4, and NetEngine 8000 M8.

CR5D00E4XM25 Occupies one flexible interface card slot. Provides four 25GE/10GE interfaces for line-rate transmitting and receiving, and supports SFP28/SFP+ optical modules.

By default, 25GE/10GE auto-negotiation is supported. You can run the port-mode group-id command in the slot view to switch the mode to 10GE/GE auto-negotiation.



Item Specification
Description 4-Port 25GE(SFP28)/10GE(SFP+) MACsec Physical Interface Card (PIC)
Part Number 03033BLK
Model CR5D00E4XM25
Card type Interface Card
Silkscreen 4x25GE-SFP28
Basic function Occupies one flexible interface card slot.
Provides four 25GE/10GE interfaces for line-rate transmitting and receiving, and supports SFP28/SFP+ optical modules.
MACsec is supported.
Reliability and availability Hot swappable.
Restrictions and remarks By default, 25GE/10GE auto-negotiation is supported. You can run the port-mode group-id command in the slot view to switch the mode to 10GE/GE auto-negotiation.
Breakout supported No
Interface rate auto-sensing supported In 25GE mode, 10GE/25GE auto-sensing supported; In 10GE mode, GE/10GE auto-sensing supported.
FlexE supported No
Dimensions without packaging (H x W x D) [mm(in.)] 19.8 mm x 193.8 mm x 209.3 mm (0.78 in. x 7.63 in. x 8.24 in.)
Dimensions with packaging (H x W x D) [mm(in.)] 70 mm x 285 mm x 300 mm (2.76 in. x 11.22 in. x 11.81 in.)
Weight without packaging [kg(lb)] 0.7 kg (1.54 lb)
Weight with packaging [kg(lb)] 1.1 kg (2.43 lb)
Typical power consumption [W] 25.3 W
Typical heat dissipation [BTU/hour] 82.15 BTU/hour
Long-term operating temperature [°C(°F)] –40°C to +65°C (–40°F to +149°F)



Product Model NetEngine 8000 M14 NetEngine 8000 M8 NetEngine 8000 M6 NetEngine 8000 M4
Switching Capacity 4 Tbit/s 2.4 Tbit/s 320 Gbit/s 2.4 Tbps
Forwarding Performance 906 Mpps 453 Mpps 72 Mpps 455 Mpps
Maximum Board Capability 200 Gbit/s 200 Gbit/s 50 Gbit/s 200 Gbps
Capacity Density (G/U) 400 400 80 800
Main Control Board 2, 1:1 2, 1:1 2, 1:1 Single
SFU 2, 1:1 2, 1:1 2, 1:1 2，1+1
(integrated) (integrated) (integrated) (integrated)
Line Card 14(DC) 8(DC) 6(DC) 4
10(AC) 8(AC) 4(AC)
Power Module 2, 1 + 1 (DC) 2, 1 + 1 2, 1 + 1 2, 1 + 1
4, 2 + 2 (AC)
Fan Module 4, 3 + 1 2, 1 + 1 2, 1 + 1 2，1+1
Dimensions (H x W x D) 222 (5U) x 442 x 220mm 132.6 (3U) x 442 x 220mm 88.9 (2U) x 442 x 220mm 88.4mm (2U) x 442mm x 220mm
Typical Power Consumption 1270 W 485 W 220 W 305.1 W
Weight in Full Configuration 27.4 kg 16.5 kg 3.52 kg 7.2 kg (15.87 lb)

Huawei NE8000 M4, M8 and M14 4-Port 25GE(SFP28)/10GE(SFP+) MACsec Physical Interface Card (PIC) CR5D00E4XM25 PN# 03033BLK

CR5D00E4XM25 is 8-Port 100/1000Base-RJ45 Physical Interface Card(PIC) used for Huawei NE8000 Series Router NetEngine 8000 M14, NetEngine 8000 M4, and NetEngine 8000 M8.

CR5D00E4XM25 Occupies one flexible interface card slot. Provides four 25GE/10GE interfaces for line-rate transmitting and receiving, and supports SFP28/SFP+ optical modules.

By default, 25GE/10GE auto-negotiation is supported. You can run the port-mode group-id command in the slot view to switch the mode to 10GE/GE auto-negotiation.


Item Specification
Description 4-Port 25GE(SFP28)/10GE(SFP+) MACsec Physical Interface Card (PIC)
Part Number 03033BLK
Model CR5D00E4XM25
Card type Interface Card
Silkscreen 4x25GE-SFP28
Basic function Occupies one flexible interface card slot.
Provides four 25GE/10GE interfaces for line-rate transmitting and receiving, and supports SFP28/SFP+ optical modules.
MACsec is supported.
Reliability and availability Hot swappable.
Restrictions and remarks By default, 25GE/10GE auto-negotiation is supported. You can run the port-mode group-id command in the slot view to switch the mode to 10GE/GE auto-negotiation.
Breakout supported No
Interface rate auto-sensing supported In 25GE mode, 10GE/25GE auto-sensing supported; In 10GE mode, GE/10GE auto-sensing supported.
FlexE supported No
Dimensions without packaging (H x W x D) [mm(in.)] 19.8 mm x 193.8 mm x 209.3 mm (0.78 in. x 7.63 in. x 8.24 in.)
Dimensions with packaging (H x W x D) [mm(in.)] 70 mm x 285 mm x 300 mm (2.76 in. x 11.22 in. x 11.81 in.)
Weight without packaging [kg(lb)] 0.7 kg (1.54 lb)
Weight with packaging [kg(lb)] 1.1 kg (2.43 lb)
Typical power consumption [W] 25.3 W
Typical heat dissipation [BTU/hour] 82.15 BTU/hour
Long-term operating temperature [°C(°F)] –40°C to +65°C (–40°F to +149°F)

Huawei NE8000 M Series M14/M8/M6/M4 Specification

Product Model NetEngine 8000 M14 NetEngine 8000 M8 NetEngine 8000 M6 NetEngine 8000 M4
Switching Capacity 4 Tbit/s 2.4 Tbit/s 320 Gbit/s 2.4 Tbps
Forwarding Performance 906 Mpps 453 Mpps 72 Mpps 455 Mpps
Maximum Board Capability 200 Gbit/s 200 Gbit/s 50 Gbit/s 200 Gbps
Capacity Density (G/U) 400 400 80 800
Main Control Board 2, 1:1 2, 1:1 2, 1:1 Single
SFU 2, 1:1 2, 1:1 2, 1:1 2，1+1
(integrated) (integrated) (integrated) (integrated)
Line Card 14(DC) 8(DC) 6(DC) 4
10(AC) 8(AC) 4(AC)
Power Module 2, 1 + 1 (DC) 2, 1 + 1 2, 1 + 1 2, 1 + 1
4, 2 + 2 (AC)
Fan Module 4, 3 + 1 2, 1 + 1 2, 1 + 1 2，1+1
Dimensions (H x W x D) 222 (5U) x 442 x 220mm 132.6 (3U) x 442 x 220mm 88.9 (2U) x 442 x 220mm 88.4mm (2U) x 442mm x 220mm
Typical Power Consumption 1270 W 485 W 220 W 305.1 W
Weight in Full Configuration 27.4 kg 16.5 kg 3.52 kg 7.2 kg (15.87 lb)
