Huawei S5735-S48T4X Switch
Review: 5 - "A masterpiece of literature" by , written on May 4, 2006
I really enjoyed this book. It captures the essential challenge people face as they try make sense of their lives and grow to adulthood.

Huawei S5735-S48T4X Switch

  • Brand New Condition
  • Original Box Packed
  • Latest Firmware Version
Available:In Stock
$0.00

Huawei CloudEngine S5735-S48T4X switch with 48-port 1000BASE-T, 4-port 10GE SFP+, 2 power slots PN# 98010941

Forwarding performance: 132 Mpps

Switching capacity: 176 Gbps/432 Gbps

Applicable power module:
PAC60S12-AR (60 W AC&240 V DC Power Module)
PDC1000S12-DB (1000 W DC Power Module)
PDC180S12-CR (180 W DC Power Module)

Huawei CloudEngine S5735-S is a series of standard gigabit access switches that provide 24–48 flexible all-GE downlink ports and four fixed 10 GE uplink ports.

S5735-S switches are designed for scenarios such as enterprise campus network access and aggregation, as well as data center access. Built on next-generation, high-performance hardware and with the Huawei Versatile Routing Platform (VRP), CloudEngine S5735-S switches boast advanced features, such as enhanced Layer 3 functionality, simplified O&M, flexible Ethernet networking, and mature IPv6 capabilities.



Specification
Physical specifications Dimensions (H x W x D) 43.6 mm x 442 mm x 420mm
Chassis height 1 U
Chassis weight (including packaging) 7.69 kg
Fixed port GE port 48
10GE port 4
Management port ETH management port Supported
Console port (RJ45) Supported
USB port USB 2.0
CPU Frequency 1000 MHz
Core 4
Storage Memory (RAM) 1 GB
Flash memory Hardware: 512MB, of which 306MB is available for users
Power supply system Power supply type 60 W AC 1000 W DC
Power supply redundancy 1+1 NOTE: the backup power supply is optional.
Rated voltage range AC input (60 W AC ): 100 V AC to 240 V AC, 50/60 Hz

 DC input (1000 W DC): -48 VDC to -60 V DC

Maximum voltage range AC input (60 W AC ): 90 V AC to 264 V AC, 47 Hz to 63 Hz

High-voltage DC input (60 W AC): 190 V DC to 290 V DC(meeting 240 V high-voltage DC certification)DC input (1000 W DC): -36 V DC to -72V DC

Maximum input current 60 W AC: 2 A 1000 W DC: 30 A
Maximum power consumption of the device 59 W
Power consumption in the case of 30% traffic load1 40 W
Power consumption in the case of 100% traffic load1 48 W
Reliability MTBF (year)2 74.7
MTTR (hour) 1.61
Availability > 0.99999

Huawei CloudEngine S5735-S48T4X switch with 48-port 1000BASE-T, 4-port 10GE SFP+, 2 power slots PN# 98010941

Forwarding performance: 132 Mpps

Switching capacity: 176 Gbps/432 Gbps

Applicable power module:
PAC60S12-AR (60 W AC&240 V DC Power Module)
PDC1000S12-DB (1000 W DC Power Module)
PDC180S12-CR (180 W DC Power Module)

Huawei CloudEngine S5735-S is a series of standard gigabit access switches that provide 24–48 flexible all-GE downlink ports and four fixed 10 GE uplink ports.

S5735-S switches are designed for scenarios such as enterprise campus network access and aggregation, as well as data center access. Built on next-generation, high-performance hardware and with the Huawei Versatile Routing Platform (VRP), CloudEngine S5735-S switches boast advanced features, such as enhanced Layer 3 functionality, simplified O&M, flexible Ethernet networking, and mature IPv6 capabilities.



Specification
Physical specifications Dimensions (H x W x D) 43.6 mm x 442 mm x 420mm
Chassis height 1 U
Chassis weight (including packaging) 7.69 kg
Fixed port GE port 48
10GE port 4
Management port ETH management port Supported
Console port (RJ45) Supported
USB port USB 2.0
CPU Frequency 1000 MHz
Core 4
Storage Memory (RAM) 1 GB
Flash memory Hardware: 512MB, of which 306MB is available for users
Power supply system Power supply type 60 W AC 1000 W DC
Power supply redundancy 1+1 NOTE: the backup power supply is optional.
Rated voltage range AC input (60 W AC ): 100 V AC to 240 V AC, 50/60 Hz

 DC input (1000 W DC): -48 VDC to -60 V DC

Maximum voltage range AC input (60 W AC ): 90 V AC to 264 V AC, 47 Hz to 63 Hz

High-voltage DC input (60 W AC): 190 V DC to 290 V DC(meeting 240 V high-voltage DC certification)DC input (1000 W DC): -36 V DC to -72V DC

Maximum input current 60 W AC: 2 A 1000 W DC: 30 A
Maximum power consumption of the device 59 W
Power consumption in the case of 30% traffic load1 40 W
Power consumption in the case of 100% traffic load1 48 W
Reliability MTBF (year)2 74.7
MTTR (hour) 1.61
Availability > 0.99999
